# Microsoft Dynamics 365

{% hint style="info" %}
With this integration you can activate segments and models from DinMo and map them to objects within **Microsoft Dynamics 365** via **Dataverse Web API**. This allows your sales and marketing teams to work with always-up-to-date data directly inside Dynamics (Contacts, Accounts, Leads, custom tables, etc.).
{% endhint %}

### Prerequisites

Before creating the destination in DinMo, you need:

* A **Dynamics 365** environment with Dataverse enabled.
* An **Azure Entra ID** (Azure AD) tenant for this environment.
* A **Web API endpoint** for your Dataverse environment, for example:\
  `https://org1234567.crm4.dynamics.com/api/data/v9.2/`
* An **App registration** in Entra ID configured for **client credentials**.
* An **Application user** in Dataverse based on this app registration, with a security role that grants access to the tables DinMo will write to.

You will need the following values to configure the destination:

1. **Web API endpoint**
2. **Tenant ID**
3. **Client ID**
4. **Client Secret**

### Step 1 – Find your Web API endpoint

1. Sign in to **Dynamics 365** and open the environment where you want to sync data.
2. Go to **Advanced Settings** → **Settings** → **Customizations** → **Developer Resources**.
3. Copy the **Web API** URL, which looks like:

   ```
   https://org1234567.crm4.dynamics.com/api/data/v9.2/
   ```
4. This value will be used as the **Web API endpoint** in DinMo.

<figure><img src="/files/k7Yk81GrOsWzshKRDy4C" alt=""><figcaption></figcaption></figure>

### Step 2 – Create an App registration (client credentials)

1. Open the **Azure portal** and navigate to **Microsoft Entra ID**.
2. Go to **App registrations** → **New registration**.
3. Set:
   * **Name**: e.g. `DinMo – Dynamics 365`
   * **Supported account types**: *Accounts in this organizational directory only*
4. After creation, note:
   * **Application (client) ID** → will be the **Client ID**
   * **Directory (tenant) ID** → will be the **Tenant ID**
5. In **Certificates & secrets**, create a **New client secret**:
   * Copy the **secret value** and store it securely. This will be the **Client Secret** used by DinMo.
6. No redirect URI is required for client credentials.

DinMo will use these values to request OAuth2 access tokens via the **client\_credentials** flow.

### Step 3 – Create the Application user in Dataverse

To allow the app to access data in Dataverse:

1. Go to the **Power Platform admin center** and open your Dynamics environment.
2. Under **Settings**, navigate to **Users + permissions** → **Application users**.
3. Click **New app user** (or **+ New**) and:
   * Select your environment.
   * Choose the **App registration** created in the previous step.
4. Assign an appropriate **Security role**, for example:
   * A dedicated role such as `DinMo Integration`, with:
     * Read / Write on the relevant tables (e.g. `contacts`, `accounts`, `leads`, custom tables).
     * Read on reference / lookup tables as needed.
5. Save the user.

This Application user will appear as the “actor” for all writes performed by DinMo in Dynamics 365.

### Step 4 – Create the Dynamics 365 destination in DinMo

1. In DinMo, go to the **Destinations** section.
2. Click **New destination**.
3. Select **Microsoft Dynamics 365** from the list of destination platforms.
4. In the connection form, fill in the following fields:

#### Authentication settings

* **Web API endpoint**\
  The full Dataverse Web API URL, for example:\
  `https://org1234567.crm4.dynamics.com/api/data/v9.2/`
* **Tenant ID**\
  Your **Directory (tenant) ID** from the App registration, for example:\
  `3ae5e114-e015-4601-9485-d6f4748c0182`
* **Client ID**\
  The **Application (client) ID** of the App registration, for example:\
  `c91bf891-e59c-41c0-971e-21fd84d20cc3`
* **Client Secret**\
  The client secret value created in **Certificates & secrets**. DinMo will encrypt this value at rest.

5. Click **Test connection** to verify that DinMo can obtain a token and reach the Web API endpoint.
6. Save the destination.

Once the destination is created, it can be reused across multiple activations.

### Supported objects and sync behavior

DinMo connects to **Dataverse** and writes directly into tables used by Dynamics 365 applications.

Typical use cases include:

* **Contacts**
  * Sync customer identifiers, personal data, and marketing attributes into the `contacts` table.
* **Accounts**
  * Sync company-level information into the `accounts` table and link contacts to accounts.
* **Leads / Opportunities** (optional)
  * Enrich or create leads/opportunities based on segments in DinMo.
* **Custom Tables**
  * Write to custom Dataverse tables when your Dynamics implementation uses them for advanced processes.

For each activation, you will:

* Choose the **target table** (e.g. `contacts`).
* Define the **primary key strategy** (e.g. Dataverse GUID, alternate keys using external IDs or email).
* Map DinMo fields to Dataverse columns.
* Configure how DinMo handles **create / update** (upsert) and **optional deletions**.

### Best practices

* **Use alternate keys for idempotent syncs**\
  Configure alternate keys on fields like external customer ID or email address so DinMo can safely upsert records without relying solely on GUIDs.
* **Limit the security role to what DinMo needs**\
  Start with a broad role during setup, then refine it to only the tables and operations required for your use cases.
* **Use a dedicated environment for testing**\
  Validate your mappings and sync behaviour in a sandbox environment before enabling syncs against production.
* **Monitor API limits**\
  Dynamics and Dataverse enforce API limits and throttling. Prefer incremental syncs and batch sizes aligned with Microsoft recommendations.

### Troubleshooting

* **403 – Forbidden**
  * Check that the **Application user** exists in the target environment.
  * Verify that the Application user has a **security role** with at least Read/Write on the relevant tables.
  * Confirm that the **Web API endpoint** host matches the one used in the OAuth scope (internally used by DinMo).
* **401 – Unauthorized**
  * Tenant ID, Client ID, or Client Secret is incorrect or expired.
  * The App registration does not allow client credentials, or the secret has been deleted or rotated.
* **Connection test fails**
  * Confirm that the Web API endpoint is reachable and points to the correct environment.
  * Make sure the Dynamics environment is active and Dataverse is provisioned.

***
